YLD-100A single-sided heavy rotors dynamic balancing machine

YLD-100A single-sided heavy rotors dynamic balancing machine

EMAIL

YLD-100A single-sided turboshaft dynamic balancing equipment

The measuring unit employs GB-2000 microcomputer balance measurement system is a system of top function and precisionIt can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer mainboard which equiped with 15-inch LCD screen and 1G Memory, Electric board 4G, Windows XP Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments.



YLD-100A single-sided turboshaft dynamic balancing equipment

YLD-100A single-sided turboshaft dynamic balancing equipment



YLD-100A single-sided turboshaft dynamic balancing equipment



Series product

 YLD-100A single-sided turboshaft dynamic balancing equipment



ModelYLD-1AYLD-5YLD-16YLD-16A
Max. Weight of workpiece(kg)0.05-1 0.1-50.5-515401
Max.diameter of workpiece(mm)φ300φ500φ500φ500
Adjusting speed form Variablefrequency
speed regulation
Single speed motor Two speed motor Frequency control moor
Balanncing speed min(r/mm)250-1500900600-900250-2500
Min. achievableresidualun balance(g.mm/kg)≤3≤3≤3≤3
Unbvalance reduction ratio(%)≥90≥90≥90≥90
Drive power(kw)0.120.370.65-0.851.1



ModelYLD-42AYLD-100AYLD-200A
Max. Weight of workpiece(kg)0.3-165-10010-200
Max.diameter of workpiece(mm)φ800φ800φ800
Adjusting speed form Frequency control moor Frequency control moor Frequency control moor
Balanncing speed min(r/mm)250-2500250-2500250-2500
Min. achievableresidualun balance(g.mm/kg)≤3≤3≤3
Unbvalance reduction ratio(%)≥90≥90≥90
Drive power(kw)1.544

YLD-100A single-sided turboshaft dynamic balancing equipment

Product application

YLD-100A single-sided turboshaft dynamic balancing equipment

The balancing machine is a new and widely-used device which has been available and developed in recent years. It is mainly applied to balance all kinds of discoid parts, such as fan blade, brake disk,brake drum.saw blade.clutch,belt pulley,chuck,pump impeller,flywheel,grinding wheel,range hood fan,brake, torque converter,tool etc .High speed and precision are advanages of this balancing machine.

YLD-100A single-sided turboshaft dynamic balancing equipment

Product feature

YLD-100A single-sided turboshaft dynamic balancing equipment



Operation interface

YLD-100A single-sided turboshaft dynamic balancing equipment



Product advantage

YLD-100A single-sided turboshaft dynamic balancing equipment



Packaging & Shipping

 YLD-100A single-sided turboshaft dynamic balancing equipment
