YLD-100A single-sided turboshaft dynamic balancing equipment

The measuring unit employs GB-2000 microcomputer balance measurement system is a system of top function and precisionIt can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer mainboard which equiped with 15-inch LCD screen and 1G Memory, Electric board 4G, Windows XP Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments.

Series product

YLD-100A single-sided turboshaft dynamic balancing equipment

Model	YLD-1A	YLD-5	YLD-16	YLD-16A
Max. Weight of workpiece(kg)	0.05-1	0.1-5	0.5-5	15401
Max.diameter of workpiece(mm)	φ300	φ500	φ500	φ500
Adjusting speed form	Variablefrequency speed regulation	Single speed motor	Two speed motor	Frequency control moor
Balanncing speed min(r/mm)	250-1500	900	600-900	250-2500
Min. achievableresidualun balance(g.mm/kg)	≤3	≤3	≤3	≤3
Unbvalance reduction ratio(%)	≥90	≥90	≥90	≥90
Drive power(kw)	0.12	0.37	0.65-0.85	1.1

Model	YLD-42A	YLD-100A	YLD-200A
Max. Weight of workpiece(kg)	0.3-16	5-100	10-200
Max.diameter of workpiece(mm)	φ800	φ800	φ800
Adjusting speed form	Frequency control moor	Frequency control moor	Frequency control moor
Balanncing speed min(r/mm)	250-2500	250-2500	250-2500
Min. achievableresidualun balance(g.mm/kg)	≤3	≤3	≤3
Unbvalance reduction ratio(%)	≥90	≥90	≥90
Drive power(kw)	1.5	4	4

Product application

YLD-100A single-sided turboshaft dynamic balancing equipment

The balancing machine is a new and widely-used device which has been available and developed in recent years. It is mainly applied to balance all kinds of discoid parts, such as fan blade, brake disk,brake drum.saw blade.clutch,belt pulley,chuck,pump impeller,flywheel,grinding wheel,range hood fan,brake, torque converter,tool etc .High speed and precision are advanages of this balancing machine.
